647000-3
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings 03P MTA100 PSTD CON ASY SN WHT W/RD STRP
PDF
/
Buying Options
Total Price: USD $0.58
Unit Price: USD $0.5808
≥1 USD $0.5808
≥10 USD $0.56408
≥100 USD $0.426624
≥500 USD $0.353153
≥1000 USD $0.308123
≥3000 USD $0.293339
Inventory: 140
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 V-2
Lead Free Not Applicable
RoHS Status RoHS Compliant
Dimensions
Plating Thickness 1.27μm
Width 21.4mm
Length 10.16mm
Height 12.55mm
Technical
Insulation Diameter 1.52 mm
Mating Retention With
Insulator Color RED
Circuit Application Signal
Contact Current Rating 5A
Sealable No
Insertion Force-Max 8.896 N
Contact Pattern RECTANGULAR
Wire/Cable Gauge 22 AWG
Durability 25 Cycles
Dielectric Withstanding Voltage 750VAC V
Polarization Key POLARIZED HOUSING
Max Voltage Rating (AC) 250V
ELV Compliant
Contact Resistance 6mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 5A
Operating Supply Voltage 250V
Housing Color Red, White
UL Flammability Code 94V-2
Contact Gender Female
Body Breadth 0.494 inch
Number of Contacts 3
Approval Agency CSA
Reliability COMMERCIAL
Voltage - Rated AC 250V
Current Rating 5A
Orientation Straight
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Voltage - Rated 250V
Number of Rows 1
Min Operating Temperature -67°C
Max Operating Temperature 221°C
Connector Type Connector, Pin, Plug
ECCN Code EAR99
Termination IDC
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2008
Physical
Underplate Material Nickel
Housing Material Nylon
Mount Cable
Contact Plating Tin
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 18 Weeks
