644726-5
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
FEED THRU WITH POLARIZING TAB Free Hanging Rectangular Connector
PDF
/
Inventory: 1404
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material COPPER ALLOY
Mount Free Hanging
Mounting Type Free Hanging (In-Line), Right Angle
Housing Material Nylon
Technical
Packaging Bulk
Published 2014
Series MTA-100
Feature Feed Through
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Connector Type Receptacle
Number of Positions 5
Color Blue
Number of Rows 1
Additional Feature FEED THRU WITH POLARIZING TAB
Fastening Type Locking Ramp
Subcategory Headers and Edge Type Connectors
Contact Type Female Socket
Pitch 0.100 2.54mm
Total Number of Contacts 5
Reference Standard UL, CSA
Contact Finish Gold
Reliability COMMERCIAL
Shrouding No
Rated Current (Signal) 5A
Contact Resistance 6mOhm
Wire Gauge 26 AWG
Body/Shell Style PLUG
Termination Type IDC
Polarization Key POLARIZED HOUSING
Wire/Cable Type Discrete
Wire/Cable Gauge 26 AWG
Cable Termination IDC
Insertion Force-Max 8.896 N
Wire Type Discrete or Ribbon Cable
Contact Design PREASSEM CONN
Wire Size (Max) 22 AWG
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Plating Thickness 30μin
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
