644463-9 image
Favorite
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description CONN RCPT 9P IDC 22AWG TIN-LEAD
PDF
/
Inventory: 9190
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Contact Plating Lead, Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Housing Material Nylon

Technical

Packaging Bulk
Published 2014
Series MTA-156
Feature Closed End, Polarizing Key
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination IDC
Connector Type Receptacle
Number of Positions 9
Color Red
Number of Rows 1
Voltage - Rated 600V
Contact Type Female Socket
Pitch 0.156 3.96mm
Current Rating 7A
Contact Finish Tin-Lead
Shrouding No
Contact Gender Female
Housing Color Red
Wire Gauge 22 AWG
Wire/Cable Type Discrete
Wire/Cable Gauge 22 AWG
Cable Termination IDC
Wire Type Discrete or Ribbon Cable

Dimensions

Contact Finish Thickness 80.0μin 2.03μm

Compliance

RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
