644382-2
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings 02P MTA156 QUAD ASSY W/TBS C/E
PDF
/
Inventory: 4502
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
Dimensions
Contact Finish Thickness 80.0μin 2.03μm
Technical
Wire Type Discrete or Ribbon Cable
Cable Termination IDC
Wire/Cable Gauge 20 AWG
Wire/Cable Type Discrete
Polarization Key POLARIZED HOUSING
Termination Type IDC
ELV Compliant
Insulation Resistance 5000000000Ohm
Wire Gauge 20 AWG
Contact Resistance 3mOhm
Rated Current (Signal) 7A
Body Depth 0.73 inch
UL Flammability Code 94V-0
Operating Temperature (Min) -55°C
Contact Gender Female
Body Breadth 0.355 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
Shrouding No
Reliability COMMERCIAL
Contact Finish Tin-Lead
Reference Standard UL, CSA
Total Number of Contacts 2
Pitch 0.156 3.96mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Fastening Type Locking Ramp
HTS Code 8536.69.40.40
Additional Feature AMP
Number of Rows 1
Color Black
Number of Positions 2
Connector Type Receptacle
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Feature Closed End, Polarizing Key
JESD-609 Code e0
Series MTA-156
Published 2010
Packaging Bulk
Physical
Housing Material Nylon
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Lead, Tin
