644284-8
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
CLOSED END W/ POLARIZING TAB Free Hanging Rectangular Connector
PDF
/
Inventory: 3458
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-2
RoHS Status Non-RoHS Compliant
Dimensions
Contact Finish Thickness 15.0μin 0.38μm
Technical
Contact Design PREASSEM CONN
Wire Type Discrete or Ribbon Cable
Cable Termination IDC
Wire/Cable Gauge 18 AWG
Durability 25 Cycles
Wire/Cable Type Discrete
Polarization Key POLARIZED HOUSING
ELV Non-Compliant
Body/Shell Style PLUG
Insulation Resistance 5000000000Ohm
Wire Gauge 18 AWG
Contact Resistance 3mOhm
Rated Current (Signal) 7A
Body Depth 0.725 inch
Operating Temperature (Min) -55°C
Body Breadth 0.355 inch
Shrouding No
Reliability COMMERCIAL
Voltage - Rated AC 600V
Contact Finish Gold
Reference Standard UL, CSA
Current Rating 7A
Total Number of Contacts 8
Pitch 0.156 3.96mm
Contact Type Female Socket
Subcategory Headers and Edge Type Connectors
Fastening Type Locking Ramp
Additional Feature CLOSED END W/ POLARIZING TAB
Number of Rows 1
Color Orange
Number of Positions 8
Connector Type Receptacle
Termination IDT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Closed End, Polarizing Key
Series MTA-156
Published 2015
Packaging Bulk
Physical
Housing Material Nylon
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Bronze
