644042-9
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings 09P MTA100 CONN ASSY 30AU
PDF
/
Buying Options
Total Price: USD $4.11
Unit Price: USD $4.110831
≥1 USD $4.110831
≥10 USD $3.878142
≥100 USD $3.658623
≥500 USD $3.451529
≥1000 USD $3.256164
Inventory: 9817
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Lifecycle Status ACTIVE (Last Updated: 5 months ago)
Physical
Contact Material PHOSPHOR BRONZE
Mount Free Hanging
Mounting Type Free Hanging (In-Line), Right Angle
Housing Material Nylon
Underplate Material Nickel
Technical
Packaging Bulk
Published 2008
Series MTA-100
Feature Closed End
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Connector Type Receptacle
Number of Positions 9
Max Operating Temperature 221°C
Min Operating Temperature -67°C
Color Red
Number of Rows 1
Voltage - Rated 250V
Fastening Type Locking Ramp
Subcategory Headers and Edge Type Connectors
Contact Type Female Socket
Pitch 0.100 2.54mm
Total Number of Contacts 19
Orientation Right Angle
Depth 6.99mm
Current Rating 5A
Contact Finish Gold
Voltage - Rated AC 250V
Reliability COMMERCIAL
Approval Agency CSA
Body Breadth 0.52 inch
Contact Gender Female
Operating Supply Voltage 250V
Rated Current (Signal) 4A
Contact Resistance 6mOhm
Wire Gauge 22 AWG
Body/Shell Style PLUG
ELV Compliant
Max Voltage Rating (AC) 250V
Dielectric Withstanding Voltage 750VAC V
Wire/Cable Type Discrete
Wire/Cable Gauge 22 AWG
Cable Termination IDC
Sealable No
Contact Current Rating 5A
Circuit Application Signal
Mating Retention With
Insulation Diameter 1.52 mm
Wire Type Discrete or Ribbon Cable
Wire Size (Min) 28 AWG
Dimensions
Height 6.99mm
Length 22.86mm
Width 13.208mm
Contact Finish Thickness 30.0μin 0.76μm
Plating Thickness 760 nm
Compliance
RoHS Status Non-RoHS Compliant
Flammability Rating UL94 V-2
Lead Free Not Applicable
