643820-9
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
CONN RCPT 9P IDC 24AWG TIN-LEAD
PDF
/
Inventory: 7490
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Plating Lead, Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Housing Material Nylon
Technical
Packaging Bulk
Published 2011
Series MTA-156
JESD-609 Code e3
Feature Closed End, Polarizing Key
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Connector Type Receptacle
Number of Positions 9
Color White
Number of Rows 1
Voltage - Rated 600V
Additional Feature CLOSED END & POLARIZING TAB
Fastening Type Locking Ramp
Subcategory Headers and Edge Type Connectors
Contact Type Female Socket
Pitch 0.156 3.96mm
Total Number of Contacts 9
Current Rating 7A
Reference Standard UL, CSA
Contact Finish Tin-Lead
Reliability COMMERCIAL
Shrouding No
Body Breadth 0.355 inch
Contact Gender Female
Operating Temperature (Min) -55°C
Body Depth 0.725 inch
Rated Current (Signal) 7A
Contact Resistance 3mOhm
Wire Gauge 24 AWG
Insulation Resistance 5000000000Ohm
Body/Shell Style PLUG
Termination Type IDC
Polarization Key POLARIZED HOUSING
Wire/Cable Type Discrete
Durability 25 Cycles
Wire/Cable Gauge 24 AWG
Cable Termination IDC
Insertion Force-Max 8.0064 N
Wire Type Discrete or Ribbon Cable
Dimensions
Contact Finish Thickness 80.0μin 2.03μm
Plating Thickness 80μin
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
