641150-2
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings 02P MTA156 CONN ASSY 22AWG RED
PDF
/
Inventory: 2496
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Contact Plating Gold
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Housing Material Nylon
Technical
Packaging Bulk
Published 2007
Series MTA-156
Feature Closed End
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination IDC
Connector Type Receptacle
Number of Positions 2
Max Operating Temperature 105°C
Min Operating Temperature -55°C
Color Red
Number of Rows 1
Fastening Type Locking Ramp
Contact Type Female Socket
Pitch 0.156 3.96mm
Orientation Right Angle
Depth 9.02mm
Current Rating 7A
Contact Finish Gold
Voltage - Rated AC 600V
Shrouding No
Number of Contacts 2
Contact Gender Female
Housing Color Red, White
Contact Resistance 3mOhm
Wire Gauge 22 AWG
ELV Compliant
Max Voltage Rating (AC) 600V
Wire/Cable Type Discrete
Wire/Cable Gauge 22 AWG
Cable Termination IDC
Wire Type Discrete or Ribbon Cable
Dimensions
Length 7.92mm
Width 9.02mm
Contact Finish Thickness 15.0μin 0.38μm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Flammability Rating UL94 V-2
Lead Free Not Applicable
