6-6437020-2 image
Favorite
6-6437020-2 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description Headers & Wire Housings 609-1630CELF =FSKT IDC S 16 30AU
PDF
/
Inventory: 961
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Plating Thickness 30μin
Contact Finish Thickness 30.0μin 0.76μm

Technical

Contact Design PREASSEM CONN
Wire Type Ribbon Cable
Cable Termination IDC
Wire Gauge (Min) 28 AWG
Wire Gauge (Max) 30 AWG
Wire/Cable Type Ribbon
Dielectric Withstanding Voltage 750VAC V
Polarization Key POLARIZED HOUSING
Termination Type IDC
ELV Compliant
Row Spacing 0.100 (2.54mm)
Insulation Resistance 1000000000Ohm
Wire Gauge 28-30 AWG
Rated Current (Signal) 1A
Operating Temperature (Min) -55°C
Number of Contacts 16
Body Length or Diameter 0.976 inch
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Orientation Right Angle
Pitch 0.100 2.54mm
Contact Type Female Socket
Subcategory Headers and Edge Type Connectors
Number of Rows 2
Color Blue
Number of Positions 40
Connector Type Receptacle
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Polarizing Key
Series AMP-Latch
Published 2016
Packaging Bulk

Physical

Insulation Material THERMOPLASTIC
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Material BERYLLIUM COPPER
