6-103734-3
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings 14 MTE RCPT SR LATCH .100CL
PDF
/
Buying Options
Total Price: USD $12.81
Unit Price: USD $12.811278
≥1 USD $12.811278
≥315 USD $5.112433
≥630 USD $4.941756
≥945 USD $4.856417
Inventory: 1176
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 21 Weeks
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Physical
Contact Material Bronze
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Housing Material Thermoplastic
Technical
Packaging Tube
Published 2008
Series AMPMODU MTE
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination IDC
Connector Type Receptacle
Number of Positions 14
Max Operating Temperature 105°C
Min Operating Temperature -65°C
Color Black
Number of Rows 1
Fastening Type Latch Lock
Contact Type Female Socket
Pitch 0.100 2.54mm
Orientation Straight
Depth 15.24mm
Current Rating 3A
Contact Finish Gold
Approval Agency CSA
Number of Contacts 14
Contact Gender Female
Housing Color Black
Operating Supply Voltage 267V
Contact Resistance 15mOhm
Wire Gauge 22-26 AWG
Insulation Resistance 5GOhm
Row Spacing 2.54 mm
ELV Compliant
Wire/Cable Type Discrete
Wire Gauge (Max) 26 AWG
Wire Gauge (Min) 22 AWG
Wire/Cable Gauge 22 AWG
Cable Termination IDC
Contact Current Rating 3A
Mating Retention With
Insulation Diameter 1.37 mm
Wire Type Discrete
Dimensions
Height 2.4892mm
Length 35.51mm
Contact Finish Thickness 30.0μin 0.76μm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
