5-641218-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
MTA-156 RoHS Compliant 1997 Not Applicable Receptacle Rectangular Connector UL94V-2 20AWG 221C 7A
PDF
/
Buying Options
Total Price: USD $28.62
Unit Price: USD $28.618594
≥1 USD $28.618594
≥250 USD $11.419604
≥500 USD $11.03755
≥1000 USD $10.849806
Inventory: 1163
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Physical
Contact Plating Tin, Gold
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Housing Material Nylon
Underplate Material Nickel
Technical
Packaging Bulk
Published 1997
Series MTA-156
Feature Closed End
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination IDC
Connector Type Receptacle
Number of Positions 21
Max Operating Temperature 221°C
Min Operating Temperature -67°C
Color Yellow
Number of Rows 1
Voltage - Rated 600V
Fastening Type Locking Ramp
Contact Type Female Socket
Pitch 0.156 3.96mm
Current Rating 7A
Contact Finish Gold
Voltage - Rated AC 600V
Approval Agency CSA
Shrouding No
Number of Contacts 21
Contact Gender Female
Housing Color Yellow, White
Operating Supply Voltage 600V
Wire Gauge 20 AWG
ELV Compliant
Wire/Cable Type Discrete
Wire/Cable Gauge 20 AWG
Cable Termination IDC
Sealable No
Contact Current Rating 7A
Circuit Application Signal
Mating Retention With
Insulation Diameter 2.41 mm
Wire Type Discrete or Ribbon Cable
Contact Retention With
Mating Alignment Without
Dimensions
Height 9.02mm
Length 83.21mm
Width 9.017mm
Contact Finish Thickness 30.0μin 0.76μm
Plating Thickness 760 nm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-2
Lead Free Not Applicable
