5-641148-4
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings 24P MTA156 ASSY 18AWG ORA LF
PDF
/
Buying Options
Total Price: USD $31.87
Unit Price: USD $31.866709
≥1 USD $31.866709
≥200 USD $12.715437
≥500 USD $12.290057
≥1000 USD $12.079993
Inventory: 1163
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Plating Thickness 380 nm
Contact Finish Thickness 3.00μin 0.076μm
Width 9.017mm
Length 95.1mm
Height 9.02mm
Technical
Mating Alignment Without
Contact Retention With
Wire Type Discrete or Ribbon Cable
Insulation Diameter 2.41 mm
Mating Retention Without
Circuit Application Power
Contact Current Rating 7A
Sealable No
Cable Termination IDC
Wire/Cable Gauge 18 AWG
Wire/Cable Type Discrete
ELV Compliant
Wire Gauge 18 AWG
Operating Supply Voltage 600V
Housing Color Orange, White
Contact Gender Female
Number of Contacts 24
Shrouding No
Approval Agency CSA
Voltage - Rated AC 600V
Contact Finish Gold
Current Rating 7A
Pitch 0.156 3.96mm
Contact Type Female Socket
Fastening Type Locking Ramp
Voltage - Rated 600V
Number of Rows 1
Color Orange
Min Operating Temperature -67°C
Max Operating Temperature 221°C
Number of Positions 24
Connector Type Receptacle
Termination IDC
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Closed End
Series MTA-156
Published 2010
Packaging Bulk
Physical
Underplate Material Nickel
Housing Material Nylon
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin, Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
