5-640442-2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
CONN RCPT 22POS IDC 26AWG TIN
PDF
/
Buying Options
Total Price: USD $8.68
Unit Price: USD $8.679582
≥1 USD $8.679582
≥200 USD $3.46343
≥500 USD $3.347895
≥1000 USD $3.29144
Inventory: 1149
Minimum: 1
-
+
Technical Details
Technical
Wire Type Discrete or Ribbon Cable
Contact Retention With
Mating Alignment Without
Insulation Diameter 1.52 mm
Mating Retention With
Circuit Application Signal
Contact Current Rating 5A
Sealable No
Cable Termination IDC
Wire/Cable Gauge 26 AWG
Wire/Cable Type Discrete
ELV Compliant
Wire Gauge 26 AWG
Operating Supply Voltage 250V
Housing Color Blue, White
Number of Contacts 22
Shrouding No
Approval Agency CSA
Voltage - Rated AC 250V
Contact Finish Tin
Current Rating 5A
Pitch 0.100 2.54mm
Contact Type Female Socket
Fastening Type Locking Ramp
Voltage - Rated 250V
Number of Rows 1
Color Blue
Min Operating Temperature -67°C
Max Operating Temperature 221°C
Number of Positions 22
Connector Type Receptacle
Termination IDC
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Closed End
Series MTA-100
Published 2012
Packaging Bulk
Dimensions
Height 6.99mm
Length 55.88mm
Width 6.985mm
Plating Thickness 5.08μm
Contact Finish Thickness 80.0μin 2.03μm
Physical
Underplate Material Nickel
Housing Material Nylon
Mounting Type Free Hanging (In-Line), Right Angle
Mount Free Hanging
Contact Plating Tin
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Factory Lead Time 16 Weeks
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
Radiation Hardening No
