5-103961-8
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
AMPMODU MTE RoHS Compliant 2010 Straight Receptacle Rectangular Connector UL94V-0 26AWG 15mOhm 105C
PDF
/
Buying Options
Total Price: USD $10.03
Unit Price: USD $10.02793
≥1 USD $10.02793
≥200 USD $4.001719
≥504 USD $3.867803
≥1008 USD $3.802158
Inventory: 2257
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Length 45.72mm
Height 5.08mm
Technical
Wire Type Discrete or Ribbon Cable
Insulation Diameter 1.37 mm
Mating Retention With
Contact Current Rating 3A
Cable Termination IDC
Wire Gauge (Min) 30 AWG
Wire Gauge (Max) 26 AWG
Wire/Cable Type Discrete
ELV Compliant
Row Spacing 2.54 mm
Insulation Resistance 5GOhm
Wire Gauge 26-30 AWG
Contact Resistance 15mOhm
Operating Supply Voltage 267V
Housing Color Black
Contact Gender Female
Number of Contacts 9
Approval Agency CSA
Contact Finish Gold
Current Rating 3A
Depth 15.24mm
Orientation Straight
Pitch 0.100 2.54mm
Contact Type Female Socket
Fastening Type Latch Lock
Number of Rows 1
Color Black
Min Operating Temperature -65°C
Max Operating Temperature 105°C
Number of Positions 9
Connector Type Receptacle
Termination IDC
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Closed End
Series AMPMODU MTE
Published 2010
Packaging Tube
Physical
Housing Material Thermoplastic
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Bronze
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 16 Weeks
