4-647010-7
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
CONN PLUG 17POS IDC 26AWG GOLD
PDF
/
Inventory: 8568
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 31 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Physical
Contact Plating Tin, Gold
Mount Free Hanging
Mounting Type Free Hanging (In-Line), Right Angle
Housing Material Nylon
Underplate Material Nickel
Technical
Packaging Bulk
Published 2008
Series MTA-100
Feature Closed End
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination IDC
Connector Type Plug
Number of Positions 17
Max Operating Temperature 221°C
Min Operating Temperature -67°C
Color Blue
Number of Rows 1
Voltage - Rated 250V
Fastening Type Latch Holder
Contact Type Male Pin
Pitch 0.100 2.54mm
Current Rating 5A
Contact Finish Gold
Approval Agency CSA
Number of Contacts 17
Housing Color White
Operating Supply Voltage 250V
Wire Gauge 26 AWG
ELV Compliant
Wire/Cable Type Discrete
Wire/Cable Gauge 26 AWG
Cable Termination IDC
Sealable No
Contact Current Rating 5A
Circuit Application Signal
Mating Retention With
Insulation Diameter 1.52 mm
Wire Type Discrete or Ribbon Cable
Contact Retention With
Mating Alignment With
Dimensions
Height 12.55mm
Length 45.72mm
Width 21.4mm
Contact Finish Thickness 30.0μin 0.76μm
Plating Thickness 1.27μm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-2
