4-644663-0
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
CONN RCPT 10POS IDC 20AWG GOLD
PDF
/
Buying Options
Total Price: USD $23.82
Unit Price: USD $23.82228
≥1 USD $23.82228
≥10 USD $22.473838
≥100 USD $21.201737
≥500 USD $20.001644
≥1000 USD $18.869474
Inventory: 7847
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
Dimensions
Plating Thickness 760 nm
Contact Finish Thickness 30.0μin 0.76μm
Length 39.62mm
Height 9.02mm
Technical
Contact Retention With
Wire Type Discrete or Ribbon Cable
Insulation Diameter 2.413 mm
Number of Power Positions 10
Contact Current Rating 7A
Sealable No
Cable Termination IDC
Wire/Cable Gauge 20 AWG
Durability 25 Cycles
Wire/Cable Type Discrete
Dielectric Withstanding Voltage 2200VAC V
Polarization Key POLARIZED HOUSING
Termination Type IDC
Max Voltage Rating (AC) 600V
ELV Compliant
Wire Gauge 20 AWG
Contact Resistance 3mOhm
Rated Current (Signal) 7A
Operating Supply Voltage 600V
UL Flammability Code 94V-2
Contact Gender Female
Body Breadth 0.355 inch
Approval Agency CSA
Reliability COMMERCIAL
Voltage - Rated AC 600V
Contact Finish Gold
Current Rating 7A
Depth 9.02mm
Orientation Right Angle
Total Number of Contacts 10
Pitch 0.156 3.96mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Fastening Type Locking Ramp
HTS Code 8536.69.40.40
Number of Rows 1
Color Yellow
Min Operating Temperature -67°C
Max Operating Temperature 221°C
Connector Type Receptacle
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Closed End, Polarizing Key
JESD-609 Code e3
Series MTA-156
Published 2008
Packaging Bulk
Physical
Underplate Material Nickel
Housing Material Nylon
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Plating Tin
Contact Material COPPER ALLOY
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 17 Weeks
