4-644375-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
CONN RCPT 11POS IDC 18AWG TIN
PDF
/
Inventory: 9592
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Contact Finish Thickness 80.0μin 2.03μm
Technical
Contact Design PREASSEM CONN
Wire Type Discrete or Ribbon Cable
Cable Termination IDC
Wire/Cable Gauge 18 AWG
Durability 25 Cycles
Wire/Cable Type Discrete
Dielectric Withstanding Voltage 2200VAC V
Polarization Key POLARIZED HOUSING
Termination Type IDC
ELV Compliant
Insulation Resistance 5000000000Ohm
Wire Gauge 18 AWG
Contact Resistance 3mOhm
Rated Current (Signal) 7A
Body Depth 0.73 inch
UL Flammability Code 94V-0
Operating Temperature (Min) -55°C
Body Breadth 0.385 inch
Shrouding No
Reliability COMMERCIAL
Contact Finish Tin
Reference Standard UL, CSA
Total Number of Contacts 11
Pitch 0.156 3.96mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Fastening Type Locking Ramp
HTS Code 8536.69.40.40
Number of Rows 1
Color Black
Number of Positions 11
Connector Type Receptacle
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature Feed Through
JESD-609 Code e3
Series MTA-156
Published 2011
Packaging Bulk
Physical
Housing Material Nylon
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material COPPER ALLOY
