4-641224-2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Free Hanging Rectangular Connector
PDF
/
Inventory: 8317
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 30 Weeks
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Physical
Contact Plating Tin, Gold
Housing Material Nylon
Underplate Material Nickel
Technical
Packaging Bulk
Published 2010
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination IDC
Connector Type Connector, Receptacle, Socket
Number of Positions 12
Max Operating Temperature 221°C
Min Operating Temperature -67°C
Number of Rows 1
Gender Female
Voltage - Rated 600V
Pitch 3.9624mm
Current Rating 7A
Voltage - Rated AC 600V
Approval Agency CSA
Shrouding No
Number of Contacts 12
Housing Color Red, White
Operating Supply Voltage 600V
ELV Compliant
Wire/Cable Gauge 22 AWG
Sealable No
Contact Current Rating 7A
Circuit Application Signal
Mating Retention Without
Insulation Diameter 2.41 mm
Contact Retention With
Mating Alignment Without
Dimensions
Height 9.02mm
Length 47.55mm
Width 9.017mm
Plating Thickness 760 nm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-2
Lead Free Not Applicable
