4-641218-2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings 12P MTA156 CONN ASSY 20AWG LF
PDF
/
Buying Options
Total Price: USD $14.05
Unit Price: USD $14.04803
≥1 USD $14.04803
≥200 USD $5.606083
≥500 USD $5.418338
≥1000 USD $5.325122
Inventory: 5281
Minimum: 1
-
+
Technical Details
Technical
Connector Type Receptacle
Number of Positions 12
Max Operating Temperature 221°C
Termination IDC
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Closed End
Series MTA-156
Published 1997
Packaging Bulk
Mating Alignment Without
Contact Retention With
Wire Type Discrete or Ribbon Cable
Insulation Diameter 2.41 mm
Mating Retention With
Circuit Application Signal
Contact Current Rating 7A
Sealable No
Cable Termination IDC
Wire/Cable Gauge 20 AWG
Wire/Cable Type Discrete
ELV Compliant
Wire Gauge 20 AWG
Operating Supply Voltage 600V
Housing Color Yellow, White
Contact Gender Female
Number of Contacts 12
Shrouding No
Approval Agency CSA
Voltage - Rated AC 600V
Contact Finish Gold
Current Rating 7A
Pitch 0.156 3.96mm
Contact Type Female Socket
Fastening Type Locking Ramp
Voltage - Rated 600V
Number of Rows 1
Color Yellow
Min Operating Temperature -67°C
Physical
Underplate Material Nickel
Housing Material Nylon
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin, Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Factory Lead Time 17 Weeks
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Plating Thickness 760 nm
Contact Finish Thickness 30.0μin 0.76μm
Width 9.017mm
Length 47.55mm
Height 9.02mm
