4-641193-2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
CONN RCPT 12POS IDC 28AWG GOLD
PDF
/
Buying Options
Total Price: USD $9.52
Unit Price: USD $9.521151
≥1 USD $9.521151
≥200 USD $3.799533
≥500 USD $3.672181
≥1000 USD $3.609162
Inventory: 1190
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Plating Thickness 380 nm
Contact Finish Thickness 15.0μin 0.38μm
Width 7.747mm
Length 30.48mm
Height 6.99mm
Technical
Mating Alignment Without
Contact Retention With
Wire Type Discrete or Ribbon Cable
Insulation Diameter 1.52 mm
Mating Retention With
Circuit Application Signal
Contact Current Rating 5A
Sealable No
Cable Termination IDC
Wire/Cable Gauge 28 AWG
Wire/Cable Type Discrete
Max Voltage Rating (AC) 250V
ELV Compliant
Wire Gauge 28 AWG
Contact Resistance 6mOhm
Operating Supply Voltage 250V
Housing Color Green, White
Number of Contacts 12
Shrouding No
Approval Agency CSA
Voltage - Rated AC 250V
Contact Finish Gold
Current Rating 5A
Depth 6.99mm
Orientation Right Angle
Pitch 0.100 2.54mm
Contact Type Female Socket
Fastening Type Locking Ramp
Voltage - Rated 250V
Number of Rows 1
Color Green
Min Operating Temperature -67°C
Max Operating Temperature 221°C
Number of Positions 12
Connector Type Receptacle
Termination IDC
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Closed End
Series MTA-100
Published 2008
Packaging Bulk
Physical
Underplate Material Nickel
Housing Material Nylon
Mounting Type Free Hanging (In-Line), Right Angle
Mount Free Hanging
Contact Plating Tin, Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 16 Weeks
