4-641170-9 image
Favorite
4-641170-9 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description Headers & Wire Housings 19P MTA156 ASSY 22AWG RED LF
PDF
/
Buying Options
Total Price: USD $33.32
Unit Price: USD $33.318776
≥1 USD $33.318776
≥250 USD $13.294425
≥500 USD $12.850665
≥1000 USD $12.631411
Inventory: 1184
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Not Applicable
Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Plating Thickness 760 nm
Contact Finish Thickness 15.0μin 0.38μm
Width 9.779mm
Length 75.29mm
Height 9.779mm

Technical

Mating Alignment Without
Contact Retention With
Wire Type Discrete or Ribbon Cable
Insulation Diameter 2.41 mm
Mating Retention With
Circuit Application Signal
Contact Current Rating 7A
Sealable No
Cable Termination IDC
Wire/Cable Gauge 22 AWG
Wire/Cable Type Discrete
ELV Compliant
Wire Gauge 22 AWG
Operating Supply Voltage 600V
Housing Color Red, White
Contact Gender Female
Number of Contacts 19
Shrouding No
Approval Agency CSA
Voltage - Rated AC 600V
Contact Finish Gold
Current Rating 7A
Pitch 0.156 3.96mm
Contact Type Female Socket
Fastening Type Locking Ramp
Voltage - Rated 600V
Number of Rows 1
Color Red
Min Operating Temperature -67°C
Max Operating Temperature 221°C
Number of Positions 19
Connector Type Receptacle
Termination IDC
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Feed Through
Series MTA-156
Published 2008
Packaging Bulk

Physical

Underplate Material Nickel
Housing Material Nylon
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin, Gold

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Factory Lead Time 16 Weeks
