3-647476-9
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings 09P MTA156 PSTD CONN 18AWG LF
PDF
/
Buying Options
Total Price: USD $7.03
Unit Price: USD $7.025349
≥1 USD $7.025349
≥10 USD $6.62769
≥100 USD $6.252538
≥500 USD $5.898617
≥1000 USD $5.564738
Inventory: 2550
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Contact Plating Tin, Gold
Mount Free Hanging
Mounting Type Free Hanging (In-Line), Right Angle
Housing Material Nylon
Underplate Material Nickel
Technical
Packaging Bulk
Published 2008
Series MTA-156
Feature Closed End
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination IDC
Connector Type Plug
Number of Positions 9
Max Operating Temperature 221°C
Min Operating Temperature -67°C
Color Orange
Number of Rows 1
Contact Type Male Pin
Pitch 0.156 3.96mm
Current Rating 7A
Contact Finish Gold
Approval Agency CSA
Shrouding Yes
Number of Contacts 9
Contact Gender Male
Housing Color Orange
Operating Supply Voltage 600V
Wire Gauge 18 AWG
ELV Compliant
Wire/Cable Type Discrete
Wire/Cable Gauge 18 AWG
Cable Termination IDC
Sealable No
Contact Current Rating 7A
Circuit Application Power
Number of Power Positions 9
Insulation Diameter 2.413 mm
Wire Type Discrete or Ribbon Cable
Contact Retention With
Dimensions
Height 12.3698mm
Length 39.62mm
Contact Finish Thickness 15.0μin 0.38μm
Plating Thickness 5.08μm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-2
Lead Free Not Applicable
