3-644812-6
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings 06P MTA156 PSTD CONN 18AWG LF
PDF
/
Inventory: 8955
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Contact Plating Gold, Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line), Right Angle
Housing Material Nylon
Underplate Material Nickel
Technical
Packaging Bulk
Published 2011
Series MTA-156
Feature Feed Through
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination IDC
Connector Type Plug
Number of Positions 6
Max Operating Temperature 221°C
Min Operating Temperature -67°C
Color Orange
Number of Rows 1
Voltage - Rated 600V
Contact Type Male Pin
Pitch 0.156 3.96mm
Current Rating 7A
Contact Finish Gold
Approval Agency CSA
Shrouding Yes
Number of Contacts 6
Contact Gender Male
Housing Color Orange, White
Operating Supply Voltage 600V
Wire Gauge 18 AWG
ELV Compliant
Wire/Cable Type Discrete
Wire/Cable Gauge 18 AWG
Cable Termination IDC
Sealable No
Contact Current Rating 7A
Circuit Application Power
Mating Retention With
Insulation Diameter 2.41 mm
Wire Type Discrete or Ribbon Cable
Contact Retention With
Mating Alignment With
Dimensions
Height 12.37mm
Length 27.7368mm
Width 25.65mm
Contact Finish Thickness 30.0μin 0.76μm
Plating Thickness 1.27μm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-2
Lead Free Not Applicable
