3-644687-7
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
MTA-156 RoHS Compliant 2008 Not Applicable Receptacle Rectangular Connector UL94V-2 22AWG 7A 600V
PDF
/
Inventory: 7334
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Technical
Wire Type Discrete or Ribbon Cable
Cable Termination IDC
Wire/Cable Gauge 22 AWG
Wire/Cable Type Discrete
ELV Compliant
Wire Gauge 22 AWG
Housing Color Red
Number of Contacts 7
Shrouding No
Voltage - Rated AC 600V
Contact Finish Gold
Current Rating 7A
Pitch 0.156 3.96mm
Contact Type Female Socket
Number of Rows 1
Color Red
Number of Positions 7
Connector Type Receptacle
Termination IDT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Closed End, Polarizing Key
Series MTA-156
Published 2008
Packaging Bulk
Physical
Housing Material Nylon
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Gold
