RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description MTA-156 RoHS Compliant 2009 GENERAL PURPOSE Receptacle Rectangular Connector UL94V-2 26AWG 7A 600V
PDF
/
Inventory: 8917
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Contact Material COPPER ALLOY
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Housing Material Nylon

Technical

Packaging Tape & Reel (TR)
Published 2009
Series MTA-156
JESD-609 Code e3
Feature Feed Through
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination IDT
Connector Type Receptacle
Number of Positions 8
Color Blue
Number of Rows 1
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Female Socket
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.156 3.96mm
Total Number of Contacts 8
Current Rating 7A
Contact Finish Tin
Voltage - Rated AC 600V
Shrouding No
UL Flammability Code 94V-2
Wire Gauge 26 AWG
ELV Compliant
Wire/Cable Type Discrete
Wire/Cable Gauge 26 AWG
Cable Termination IDC
Wire Type Discrete or Ribbon Cable

Dimensions

Contact Finish Thickness 80.0μin 2.03μm

Compliance

RoHS Status RoHS Compliant
Flammability Rating UL94 V-2
Lead Free Not Applicable
