281792-5
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
CONN PLUG 10POS IDC 26-28AWG TIN
PDF
/
Buying Options
Total Price: USD $1.79
Unit Price: USD $1.7864
≥1 USD $1.7864
≥10 USD $1.59368
≥100 USD $1.302189
≥500 USD $1.16468
≥1000 USD $1.027189
Inventory: 461
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Width 7.54mm
Length 13.5mm
Height 129.54mm
Technical
Wire Type Discrete
Insulation Diameter 990.6 μm
Mating Retention Without
Contact Current Rating 3A
Cable Termination IDC
Number of Poles 10
Wire/Cable Gauge 26 AWG
Wire Gauge (Min) 28 AWG
Wire Gauge (Max) 26 AWG
ELV Compliant
Row Spacing 0.100 (2.54mm)
Insulation Resistance 1GOhm
Wire Gauge 26-28 AWG
Contact Resistance 30mOhm
Working Voltage 500V
Contact Gender Female
Lead Pitch 2.54mm
Contact Finish Tin
Current Rating 3A
Orientation Straight
Pitch 0.100 2.54mm
Contact Type Female Socket
Fastening Type Detent Lock
Gender Receptacle
Number of Rows 2
Color Blue
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Connector Type Plug
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series HE13/HE14
Published 2007
Packaging Bulk
Physical
Housing Material PBT
Material Glass, Polyester
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Material Bronze
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 15 Weeks
