2-640606-3
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
AMP Rectangular Connector Panel Mount
PDF
/
Inventory: 9353
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-2
RoHS Status Non-RoHS Compliant
Dimensions
Contact Finish Thickness 80.0μin 2.03μm
Technical
Wire Type Discrete or Ribbon Cable
Cable Termination IDC
Wire/Cable Gauge 22 AWG
Wire/Cable Type Discrete
Termination Type IDC
ELV Non-Compliant
Wire Gauge 22 AWG
UL Flammability Code 94V-2
Mating Information MULTIPLE MATING PARTS AVAILABLE
Shrouding No
Voltage - Rated AC 600V
Contact Finish Tin-Lead
Current Rating 7A
Total Number of Contacts 23
Pitch 0.156 3.96mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Additional Feature AMP
Number of Rows 1
Color Red
Number of Positions 23
Connector Type Receptacle
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Feed Through
JESD-609 Code e0
Series MTA-156
Published 2014
Packaging Bulk
Physical
Housing Material Nylon
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Lead, Tin
Contact Material COPPER ALLOY
