2-640432-0 image
Favorite
2-640432-0 image
Favorite
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description CONN RCPT 20P IDC 20AWG TIN-LEAD
PDF
/
Inventory: 5403
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Contains Lead
RoHS Status Non-RoHS Compliant

Dimensions

Length - Termination 0.48 inch
Contact Finish Thickness 80.0μin 2.03μm

Technical

Wire Size (Max) 22 AWG
Wire Size (Min) 22 AWG
Contact Design PREASSEM CONN
Wire Type Discrete or Ribbon Cable
Cable Termination IDC
Wire/Cable Gauge 20 AWG
Wire/Cable Type Discrete
Termination Type IDC
Body/Shell Style PLUG
Insulation Resistance 5000000Ohm
Wire Gauge 20 AWG
Contact Resistance 3mOhm
Body Depth 0.355 inch
Operating Temperature (Min) -55°C
Body Breadth 0.725 inch
Shrouding No
Reliability COMMERCIAL
Contact Finish Tin-Lead
Reference Standard UL, CSA
Total Number of Contacts 20
Pitch 0.156 3.96mm
Contact Type Female Socket
Subcategory Headers and Edge Type Connectors
Number of Rows 1
Color Yellow
Number of Positions 20
Connector Type Receptacle
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Closed End
Series MTA-156
Published 2004
Packaging Bulk

Physical

Housing Material Nylon
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Lead, Tin
Contact Material PHOSPHOR BRONZE
