2-111494-3
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings 044 UNIV I/O 30DP SLOT LTCH
PDF
/
Buying Options
Total Price: USD $40.02
Unit Price: USD $40.019818
≥1 USD $40.019818
≥210 USD $15.968803
≥510 USD $15.434452
≥990 USD $15.17056
Inventory: 2357
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Plating Thickness 760 nm
Contact Finish Thickness 30.0μin 0.76μm
Width 8.38mm
Length 80.6704mm
Height 23.749mm
Technical
Shrouded End Dimension 3.81 mm
Mating Connector Lock With
Wire Type Ribbon Cable
Mating Post Length 6.1mm
Insulation Diameter 970 μm
Circuit Application Signal
Contact Current Rating 1A
Cable Termination IDC
Wire Gauge (Min) 26 AWG
Wire Gauge (Max) 28 AWG
Wire/Cable Type Ribbon
ELV Compliant
Row Spacing 0.100 (2.54mm)
Insulation Resistance 5GOhm
Wire Gauge 26-28 AWG
Operating Supply Voltage 250V
Lead Length 3.302mm
Approval Agency UL
Contact Finish Gold
Current Rating 1A
Pitch 0.100 2.54mm
Contact Type Male Pin
Fastening Type Latch Lock/Eject Hooks
Number of Rows 2
Color Black
Min Operating Temperature -65°C
Max Operating Temperature 105°C
Number of Positions 44
Connector Type Plug
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Feed Through
Series AMP-Latch
Published 1999
Packaging Tray
Physical
PCB Mount Retention Without
Housing Material Thermoplastic
Mounting Type Panel Mount
Mount Panel
Contact Plating Tin
Contact Material Bronze
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 9 Weeks
