172051-3
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings 3P MTEI RCPT HSG ASY 22
PDF
/
Buying Options
Total Price: USD $0.29
Unit Price: USD $0.2904
≥1 USD $0.2904
≥10 USD $0.26136
≥100 USD $0.185425
≥500 USD $0.162518
≥1000 USD $0.145068
≥3000 USD $0.134992
Inventory: 1176
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Physical
Contact Material Bronze
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Housing Material Nylon
Technical
Packaging Bulk
Published 1997
Series MTEI (Mass Termination EI)
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination IDT
ECCN Code EAR99
Connector Type Receptacle
Number of Positions 3
Max Operating Temperature 95°C
Min Operating Temperature -20°C
Color Red
Number of Rows 1
Additional Feature AMP
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Female Socket
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.098 2.50mm
Total Number of Contacts 3
Orientation Right Angle
Depth 6.5mm
Contact Finish Tin
Approval Agency UL
UL Flammability Code 94V-0
Operating Supply Voltage 250V
Contact Resistance 20mOhm
Wire Gauge 22 AWG
ELV Compliant
Max Voltage Rating (AC) 250V
Wire/Cable Type Discrete
Wire/Cable Gauge 22 AWG
Max Voltage Rating (DC) 350.25kV
Cable Termination IDC
Contact Current Rating 3.5A
Wire Type Discrete or Ribbon Cable
Dimensions
Height 13.7922mm
Length 10mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Not Applicable
