1658619-3
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings ULTRA-LITE BLINDHOLE PLUG ASY 109 3
PDF
/
Buying Options
Total Price: USD $1.71
Unit Price: USD $1.706594
≥1 USD $1.706594
≥10 USD $1.609992
≥100 USD $1.518867
≥500 USD $1.432886
≥1000 USD $1.351782
Inventory: 3342
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Contact Material Bronze
Contact Plating Gold, Nickel
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Housing Material Thermoplastic
Technical
Packaging Bulk
Published 1998
Series AMP-Latch
Feature Feed Through
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Receptacle
Number of Positions 40
Max Operating Temperature -105°C
Min Operating Temperature -65°C
Color Gray
Number of Rows 2
Contact Type Forked
Pitch 0.100 2.54mm
Orientation Right Angle
Depth 7.49mm
Contact Finish Gold
Approval Agency CSA, UL
Housing Color Black
Row Spacing 0.100 (2.54mm)
ELV Compliant
Wire/Cable Type Ribbon
Cable Termination IDC
Insulation Diameter -740 μm
Wire Type Ribbon Cable
Dimensions
Length 55.52mm
Width 7.49mm
Contact Finish Thickness 15.0μin 0.38μm
Plating Thickness 380 nm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
