111826-8
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
CONN RCPT 34P IDC 26-28AWG GOLD
PDF
/
Inventory: 9402
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Forked
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.100 2.54mm
Total Number of Contacts 34
Reach Compliance Code unknown
Contact Finish Gold
Contact Gender FEMALE
UL Flammability Code 94V-0
Empty Shell NO
Number of Rows 2
Color Black
Number of Positions 34
Connector Type Receptacle
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Feed Through, Positions Molded Closed
JESD-609 Code e0
Series AMP-Latch
Published 1998
Packaging Bulk
Wire Type Ribbon Cable
Cable Termination IDC
Wire Gauge (Min) 26 AWG
Wire Gauge (Max) 28 AWG
Wire/Cable Type Ribbon
Termination Type IDC
ELV Non-Compliant
Row Spacing 0.100 (2.54mm)
Wire Gauge 26-28 AWG, Stranded or Solid
Physical
Housing Material Plastic
Shell Material GLASS FILLED POLYBUTYLENE TEREPHTHALATE
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material PHOSPHOR BRONZE
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Contact Finish Thickness 15.0μin 0.38μm
Width 6.1mm
Length 47.8mm
Height 8.38mm
