111446-2 image
Favorite
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description CONN PLUG 14P IDC 26-28AWG GOLD
PDF
/
Inventory: 1491
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Radiation Hardening No

Dimensions

Contact Finish Thickness 30.0μin 0.76μm

Technical

Wire Type Ribbon Cable
Contact Current Rating 1A
Cable Termination IDC
Number of Poles 14
Wire/Cable Gauge 26 AWG
Wire Gauge (Min) 26 AWG
Wire Gauge (Max) 28 AWG
Wire/Cable Type Ribbon
ELV Non-Compliant
Row Spacing 0.100 (2.54mm)
Wire Gauge 26-28 AWG
Contact Resistance 15mOhm
Lead Pitch 1.27mm
Contact Finish Gold
Current Rating 1A
Pitch 0.100 2.54mm
Option GENERAL PURPOSE
Contact Type Male Pin
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Number of Rows 2
Color Black
Min Operating Temperature -65°C
Max Operating Temperature 105°C
Connector Type Plug
Termination IDT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Feature Feed Through
JESD-609 Code e0
Series AMP-Latch
Published 2011
Packaging Tray

Physical

Housing Material Plastic
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Bronze
