111446-1
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings 10 UNIV I/O 30DP N/E
PDF
/
Buying Options
Total Price: USD $15.06
Unit Price: USD $15.058963
≥1 USD $15.058963
≥220 USD $6.009143
≥550 USD $5.80827
≥990 USD $5.708489
Inventory: 9150
Minimum: 1
-
+
Technical Details
Technical
Contact Current Rating 1A
Withdrawl Force-Min .417 N
Insertion Force-Max 3.336 N
Cable Termination IDC
Wire Gauge (Min) 26 AWG
Wire Gauge (Max) 28 AWG
Wire/Cable Type Ribbon
Dielectric Withstanding Voltage 500VAC V
Polarization Key POLARIZED HOUSING
ELV Non-Compliant
Row Spacing 0.100 (2.54mm)
Insulation Resistance 5GOhm
Wire Gauge 26-28 AWG
Contact Resistance 15mOhm
Rated Current (Signal) 1A
Operating Supply Voltage 250V
Empty Shell NO
UL Flammability Code 94V-0
Contact Gender Male
Body Breadth 0.33 inch
Approval Agency UL
Reliability COMMERCIAL
Contact Finish Gold
Current Rating 1A
Depth 8.38mm
Orientation Vertical
Total Number of Contacts 10
Pitch 0.100 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Male Pin
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.30
Number of Rows 2
Color Black
Min Operating Temperature -65°C
Max Operating Temperature 105°C
Number of Positions 10
Connector Type Plug
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
Feature Feed Through
JESD-609 Code e0
Series AMP-Latch
Published 1999
Packaging Tray
Shrouded End Dimension 3.81 mm
Mating Connector Lock Without
Wire Type Ribbon Cable
Mating Post Length 6.1mm
Insulation Diameter 970 μm
Circuit Application Signal
Physical
Housing Material Thermoplastic
Shell Material POLYETHYLENE
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Material Bronze
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 15 Weeks
Compliance
Lead Free Contains Lead
Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Plating Thickness 760 nm
Contact Finish Thickness 30.0μin 0.76μm
Width 8.38mm
Length 27.2288mm
Height 14.48mm
