104892-9
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
NONE Free Hanging Rectangular Connector
PDF
/
Inventory: 4347
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Material Steel
Housing Material Plastic
Technical
Packaging Tube
Published 2014
Series AMPMODU 50/50 Grid
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Connector Type Receptacle
Number of Positions 90
Color Black
Number of Rows 2
Additional Feature NONE
Fastening Type Latch Lock
Subcategory Headers and Edge Type Connectors
Contact Type Female Socket
Pitch 0.050 1.27mm
Total Number of Contacts 90
Reach Compliance Code unknown
Reference Standard UL, CSA
Contact Finish Gold
Reliability COMMERCIAL
Operating Temperature (Max) 105°C
Operating Temperature (Min) -65°C
Body Depth 0.69 inch
Rated Current (Signal) 0.5A
Wire Gauge 28 AWG
Insulation Resistance 5000000000Ohm
Row Spacing 0.050 (1.27mm)
Body/Shell Style PLUG
Dielectric Withstanding Voltage 300VAC V
Wire/Cable Type Ribbon
Wire/Cable Gauge 28 AWG
Cable Termination IDC
Withdrawl Force-Min .139 N
Wire Type Ribbon Cable
Wire Size (Min) 30 AWG
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Plating Thickness 30μin
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
