103956-6
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
CONN RECPT 7POS .100 POLAR TIN
PDF
/
Buying Options
Total Price: USD $6.13
Unit Price: USD $6.12993
≥1 USD $6.12993
≥210 USD $2.445933
≥510 USD $2.364533
≥990 USD $2.323833
Inventory: 3290
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Physical
Contact Material Bronze
Contact Plating Lead, Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Housing Material Thermoplastic
Technical
Packaging Tube
Published 2009
Series AMPMODU MTE
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Connector Type Receptacle
Number of Positions 7
Max Operating Temperature 105°C
Min Operating Temperature -65°C
Color Black
Number of Rows 1
Fastening Type Latch Lock
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Female Socket
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.100 2.54mm
Total Number of Contacts 6
Orientation Straight
Depth 15.24mm
Current Rating 3A
Contact Finish Tin-Lead
Approval Agency CSA
Contact Gender Female
Operating Supply Voltage 267V
Contact Resistance 15mOhm
Wire Gauge 22-26 AWG
Insulation Resistance 5GOhm
Row Spacing 2.54 mm
ELV Non-Compliant
Wire/Cable Type Ribbon
Wire Gauge (Max) 22 AWG
Wire Gauge (Min) 26 AWG
Wire/Cable Gauge 22 AWG
Cable Termination IDC
Contact Current Rating 3A
Mating Retention With
Insulation Diameter 1.37 mm
Wire Type Discrete
Dimensions
Height 5.08mm
Length 35.56mm
Contact Finish Thickness 100.0μin 2.54μm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Not Applicable
