103951-2
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings 5X3 MTE PIN SR RIBBED .100CL
PDF
/
Inventory: 6990
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Contact Finish Thickness 15.0μin 0.38μm
Length 37.846mm
Height 2.4892mm
Technical
Wire Type Ribbon Cable
Mating Retention Without
Contact Current Rating 3A
Cable Termination IDC
Wire/Cable Gauge 22 AWG
Wire Gauge (Min) 22 AWG
Wire Gauge (Max) 26 AWG
Wire/Cable Type Ribbon
ELV Non-Compliant
Row Spacing 2.54 mm
Insulation Resistance 5GOhm
Wire Gauge 22-26 AWG
Operating Supply Voltage 267V
Contact Gender Male
Approval Agency CSA
Contact Finish Gold
Current Rating 3A
Total Number of Contacts 3
Pitch 0.100 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Male Pin
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Additional Feature LATCHED
Number of Rows 1
Color Black
Min Operating Temperature -65°C
Max Operating Temperature 105°C
Number of Positions 3
Connector Type Plug
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Closed End
Series AMPMODU MTE
Published 2008
Packaging Tube
Physical
Housing Material Thermoplastic
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Lead, Tin
Contact Material Bronze
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 20 Weeks
