102393-2 image
Favorite
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description CONN RCPT 8POS IDC 26-30AWG GOLD
PDF
/
Inventory: 4148
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Contact Material Bronze
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Housing Material Thermoplastic

Technical

Packaging Tray
Published 2015
Series AMPMODU MT
Feature Closed End
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Connector Type Receptacle
Number of Positions 8
Color Black
Number of Rows 2
Subcategory Headers and Edge Type Connectors
Contact Type Female Socket
Pitch 0.100 2.54mm
Total Number of Contacts 8
Reference Standard UL, CSA
Contact Finish Gold
Reliability COMMERCIAL
Lead Pitch 2.54mm
Operating Temperature (Max) 105°C
Contact Gender Female
Operating Temperature (Min) -65°C
Body Depth 0.6 inch
Rated Current (Signal) 3A
Wire Gauge 26-30 AWG
Insulation Resistance 5GOhm
Row Spacing 0.100 (2.54mm)
Body/Shell Style PLUG
ELV Non-Compliant
Wire/Cable Type Discrete
Wire Gauge (Max) 30 AWG
Wire Gauge (Min) 26 AWG
Cable Termination IDC
Withdrawl Force-Min .417 N
Contact Current Rating 3A
Wire Type Discrete or Ribbon Cable

Dimensions

Height 15.2mm
Length 10.2mm
Width 6.1mm
Contact Finish Thickness 30.0μin 0.76μm
Plating Thickness 30μin

Compliance

RoHS Status Non-RoHS Compliant
Lead Free Not Applicable
