1-644040-0
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Free Hanging Rectangular Connector
PDF
/
Inventory: 9944
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Contact Finish Thickness 15.0μin 0.38μm
Technical
Wire Size (Max) 22 AWG
Wire Type Discrete or Ribbon Cable
Insertion Force-Max 8.896 N
Cable Termination IDC
Wire/Cable Gauge 26 AWG
Durability 25 Cycles
Wire/Cable Type Discrete
Dielectric Withstanding Voltage 750VAC V
Polarization Key POLARIZED HOUSING
Termination Type IDC
Body/Shell Style PLUG
Insulation Resistance 5000000000Ohm
Wire Gauge 26 AWG
Contact Resistance 6mOhm
Rated Current (Signal) 5A
Body Depth 0.52 inch
Operating Temperature (Min) -55°C
Contact Gender Female
Body Breadth 0.275 inch
Shrouding No
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL, CSA
Current Rating 5A
Total Number of Contacts 10
Pitch 0.100 2.54mm
Contact Type Female Socket
Subcategory Headers and Edge Type Connectors
Fastening Type Locking Ramp
Voltage - Rated 250V
Number of Rows 1
Color Blue
Number of Positions 10
Connector Type Receptacle
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Closed End
Series MTA-100
Published 2015
Packaging Bulk
Physical
Housing Material Nylon
Mounting Type Free Hanging (In-Line), Right Angle
Mount Free Hanging
Contact Material COPPER ALLOY
