1-643815-2
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
CONN RCPT 12P IDC 26AWG TIN-LEAD
PDF
/
Inventory: 5663
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-2
RoHS Status Non-RoHS Compliant
Dimensions
Contact Finish Thickness 80.0μin 2.03μm
Length 30.48mm
Technical
Wire Size (Max) 22 AWG
Wire Size (Min) 28 AWG
Wire Type Discrete or Ribbon Cable
Cable Termination IDC
Wire/Cable Gauge 26 AWG
Wire/Cable Type Discrete
Dielectric Withstanding Voltage 750VAC V
Max Voltage Rating (AC) 250V
ELV Non-Compliant
Body/Shell Style PLUG
Insulation Resistance 5000000000Ohm
Wire Gauge 26 AWG
Contact Resistance 6mOhm
Rated Current (Signal) 4A
Contact Gender Female
Body Breadth 0.52 inch
Shrouding No
Reliability COMMERCIAL
Voltage - Rated AC 250V
Contact Finish Tin-Lead
Reference Standard UL, CSA
Current Rating 5A
Depth 6.99mm
Orientation Right Angle
Total Number of Contacts 12
Pitch 0.100 2.54mm
Contact Type Female Socket
Subcategory Headers and Edge Type Connectors
Fastening Type Locking Ramp
HTS Code 8536.69.40.40
Voltage - Rated 250V
Number of Rows 1
Color Blue
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Number of Positions 12
Connector Type Receptacle
ECCN Code EAR99
Termination IDT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Closed End
JESD-609 Code e4
Series MTA-100
Published 2003
Packaging Bulk
Physical
Housing Material Nylon
Mounting Type Free Hanging (In-Line), Right Angle
Mount Cable, Free Hanging
Contact Plating Tin
Contact Material PHOSPHOR BRONZE
Supply Chain
Factory Lead Time 7 Weeks
