1-643498-2
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
MTA-100 Non-RoHS Compliant COMMERCIAL UL CSA Receptacle Rectangular Connector UL94V-0 22AWG 5mOhm -55C
PDF
/
Inventory: 1349
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
Dimensions
Length - Termination 0.275 inch
Contact Finish Thickness 80.0μin 2.03μm
Technical
Wire Size (Min) 28 AWG
Wire Type Discrete or Ribbon Cable
Cable Termination IDC
Wire/Cable Gauge 22 AWG
Wire/Cable Type Discrete
Dielectric Withstanding Voltage 750VAC V
ELV Non-Compliant
Body/Shell Style PLUG
Insulation Resistance 5000000000Ohm
Wire Gauge 22 AWG
Contact Resistance 5mOhm
Rated Current (Signal) 4A
Body Depth 0.275 inch
Operating Temperature (Min) -55°C
Contact Gender Female
Body Breadth 0.52 inch
Shrouding No
Reliability COMMERCIAL
Voltage - Rated AC 250V
Contact Finish Tin-Lead
Reference Standard UL, CSA
Current Rating 5A
Total Number of Contacts 12
Pitch 0.100 2.54mm
Contact Type Female Socket
Subcategory Headers and Edge Type Connectors
Fastening Type Locking Ramp
Voltage - Rated 250V
Number of Rows 1
Color Black
Number of Positions 12
Connector Type Receptacle
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Closed End
JESD-609 Code e4
Series MTA-100
Published 2011
Packaging Bulk
Physical
Housing Material Nylon
Mounting Type Free Hanging (In-Line), Right Angle
Mount Free Hanging
Contact Plating Lead, Tin
Contact Material PHOSPHOR BRONZE
