1-641238-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings 11P MTA100 CONN ASSY NATL 30AU
PDF
/
Inventory: 3299
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
Technical
Insertion Force-Max 8.896 N
Contact Pattern RECTANGULAR
Wire/Cable Gauge 24 AWG
Durability 25 Cycles
Dielectric Withstanding Voltage 750VAC V
Polarization Key POLARIZED HOUSING
Max Voltage Rating (AC) 250V
ELV Compliant
Insulation Resistance 5000000000Ohm
Contact Resistance 6mOhm
Contact Style SQ PIN-SKT
Body Depth 0.52 inch
Housing Color White
UL Flammability Code 94V-2
Contact Gender Female
Body Breadth 0.275 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 11
Shrouding No
Reliability COMMERCIAL
Voltage - Rated AC 250V
Reference Standard UL, CSA
Current Rating 5A
Orientation Right Angle
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Additional Feature AMP
Number of Rows 1
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Connector Type Connector, Receptacle, Socket
ECCN Code EAR99
Termination IDC
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Published 2011
Packaging Bulk
Physical
Housing Material Nylon
Mount Cable
Contact Plating Gold
Contact Material COPPER ALLOY
Supply Chain
Factory Lead Time 13 Weeks
