1-103975-0
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
CONN RCPT 11P IDC 22-26AWG GOLD
PDF
/
Inventory: 7501
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Contact Finish Thickness 15.0μin 0.38μm
Length 55.88mm
Height 2.49mm
Technical
Wire Type Ribbon Cable
Insulation Diameter 1.37 mm
Mating Retention Without
Contact Current Rating 3A
Cable Termination IDC
Wire/Cable Gauge 22 AWG
Wire Gauge (Min) 26 AWG
Wire Gauge (Max) 22 AWG
Wire/Cable Type Ribbon
ELV Non-Compliant
Row Spacing 2.54 mm
Insulation Resistance 5GOhm
Wire Gauge 22-26 AWG
Contact Resistance 15mOhm
Operating Supply Voltage 267V
Housing Color Black
Contact Gender Female
Number of Contacts 11
Approval Agency CSA
Contact Finish Gold
Current Rating 3A
Orientation Straight
Pitch 0.100 2.54mm
Contact Type Female Socket
Number of Rows 1
Color Black
Min Operating Temperature -65°C
Max Operating Temperature 105°C
Number of Positions 11
Connector Type Receptacle
Termination IDC
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Closed End
Series AMPMODU MTE
Published 2010
Packaging Tube
Physical
Housing Material Thermoplastic
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Plating Lead, Tin
Contact Material Bronze
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 20 Weeks
