RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description Headers & Wire Housings 4X5 MTE RCPT SR LATCH .100CL
PDF
/
Buying Options
Total Price: USD $1.58
Unit Price: USD $1.584
≥1 USD $1.584
≥10 USD $1.409399
≥100 USD $1.294938
≥500 USD $1.037362
≥1000 USD $0.930046
Inventory: 263
Minimum: 1
-
+

Technical Details

Compliance

Flammability Rating UL94 V-0
RoHS Status RoHS Compliant

Dimensions

Contact Finish Thickness 100.0μin 2.54μm
Length 50.55mm
Height 5.08mm

Technical

Wire Type Discrete
Insulation Diameter 1.37 mm
Mating Retention With
Contact Current Rating 3A
Cable Termination IDC
Wire/Cable Gauge 22 AWG
Wire Gauge (Min) 26 AWG
Wire Gauge (Max) 22 AWG
ELV Compliant
Row Spacing 2.54 mm
Insulation Resistance 5GOhm
Wire Gauge 22-26 AWG
Operating Supply Voltage 267V
Contact Gender Female
Approval Agency CSA
Contact Finish Tin
Current Rating 3A
Total Number of Contacts 5
Pitch 0.100 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Fastening Type Latch Lock
Number of Rows 1
Color Black
Min Operating Temperature -65°C
Max Operating Temperature 105°C
Number of Positions 5
Connector Type Receptacle
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series AMPMODU MTE
Published 2009
Packaging Tube

Physical

Housing Material Thermoplastic
Mounting Type Free Hanging (In-Line)
Contact Material Bronze

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 20 Weeks
