647017-2
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings 4P MTA 15Au
PDF
/
Inventory: 7764
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material COPPER ALLOY
Contact Plating Gold
Housing Material Nylon
Technical
JESD-609 Code e0
Pbfree Code no
Termination IDC
Connector Type Connector, Receptacle, Socket
Number of Rows 1
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Reference Standard UL, CSA
Voltage - Rated AC 250V
Reliability COMMERCIAL
Body Length or Diameter 0.3 inch
Shrouding No
Number of Contacts 2
Mating Information MULTIPLE MATING PARTS AVAILABLE
Body Breadth 0.494 inch
Contact Gender Female
Operating Temperature (Min) -55°C
Housing Color White
Body Depth 0.843 inch
Rated Current (Signal) 5A
Contact Style SQ PIN-SKT
Contact Resistance 6mOhm
Insulation Resistance 5000000000Ohm
Body/Shell Style PLUG
ELV Compliant
Polarization Key POLARIZED HOUSING
Dielectric Withstanding Voltage 750VAC V
Wire/Cable Gauge 24 AWG
Contact Pattern RECTANGULAR
Insertion Force-Max 8.896 N
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-2
Lead Free Not Applicable
