644662-3
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings 03P MTA156 CONN ASSY
PDF
/
Inventory: 8799
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material PHOSPHOR BRONZE
Contact Plating Gold
Housing Material Nylon
Technical
JESD-609 Code e0
Pbfree Code no
Termination IDC
ECCN Code EAR99
Connector Type Connector, Receptacle, Socket
Number of Rows 1
Additional Feature AMP
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 3.96mm
Current Rating 7A
Reference Standard UL, CSA
Voltage - Rated AC 600V
Reliability COMMERCIAL
Body Length or Diameter 0.468 inch
Shrouding No
Number of Contacts 3
Mating Information MULTIPLE MATING PARTS AVAILABLE
Body Breadth 0.725 inch
Contact Gender Female
Operating Temperature (Min) -55°C
UL Flammability Code 94V-2
Housing Color White
Contact Style SQ PIN-SKT
Insulation Resistance 5000000Ohm
Body/Shell Style PLUG
ELV Compliant
Wire/Cable Gauge 22 AWG
Contact Pattern RECTANGULAR
Insulator Color ORANGE
Dimensions
Length - Termination 0.48 inch
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-2
Lead Free Not Applicable
