644574-4 image
Favorite
644574-4 image
Favorite
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description Headers & Wire Housings 04P MTA100 CON ASSY 24AWG BLK
PDF
/
Inventory: 9005
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Contact Material COPPER ALLOY
Contact Plating Lead, Tin
Contact Shape Square
Housing Material Nylon
Mounting Option 1 LOCKING

Technical

JESD-609 Code e0
Pbfree Code no
Termination IDC
ECCN Code EAR99
Connector Type Connector, Receptacle, Socket
Max Operating Temperature 221°C
Min Operating Temperature -67°C
Number of Rows 1
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Reference Standard UL
Voltage - Rated AC 250V
Reliability COMMERCIAL
Approval Agency CSA
Shrouding No
Number of Contacts 4
Mating Information MULTIPLE MATING PARTS AVAILABLE
Body Breadth 0.275 inch
Contact Gender Female
Housing Color Black
Body Depth 0.52 inch
Rated Current (Signal) 5A
Contact Style SQ PIN-SKT
ELV Non-Compliant
Polarization Key POLARIZED HOUSING
Dielectric Withstanding Voltage 750VAC V
Durability 25 Cycles
Wire/Cable Gauge 24 AWG
Contact Pattern RECTANGULAR
Insertion Force-Max 8.896 N
Insulation Diameter 1.52 mm
Contact Rating (Current) 5A

Dimensions

Height 6.99mm
Length 10.16mm
Plating Thickness 2.03μm

Compliance

RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Not Applicable
