644565-6
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
CONN RECEPT 6POS 28AWG MTA100
PDF
/
Inventory: 7796
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
Dimensions
Plating Thickness 5.08μm
Length 15.24mm
Height 7.75mm
Technical
Contact Rating (Current) 5A
Insulation Diameter 1.52 mm
Contact Pattern RECTANGULAR
Wire/Cable Gauge 28 AWG
Durability 25 Cycles
Wire/Cable Type Discrete
Dielectric Withstanding Voltage 750VAC V
Polarization Key POLARIZED HOUSING
Max Voltage Rating (AC) 250V
ELV Non-Compliant
Contact Resistance 6mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 5A
Body Depth 0.52 inch
Housing Color Green, White
UL Flammability Code 94V-2
Contact Gender Female
Body Breadth 0.305 inch
Number of Contacts 6
Shrouding No
Approval Agency CSA
Reliability COMMERCIAL
Voltage - Rated AC 250V
Reference Standard UL
Current Rating 5A
Orientation Right Angle
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Fastening Type Ramp
Number of Rows 1
Color Green
Min Operating Temperature -67°C
Max Operating Temperature 221°C
Connector Type Connector, Receptacle, Socket
ECCN Code EAR99
Termination IDC
Pbfree Code no
JESD-609 Code e0
Packaging Bulk
Physical
Housing Material Nylon
Contact Shape Square
Mount Cable, Free Hanging
Contact Plating Tin
Contact Material PHOSPHOR BRONZE
