644540-7
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
CONN RECEPT 7POS 22AWG MTA100
PDF
/
Inventory: 9537
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Body Depth 0.52 inch
Rated Current (Signal) 5A
Contact Style SQ PIN-SKT
Contact Resistance 6mOhm
ELV Non-Compliant
Polarization Key POLARIZED HOUSING
Wire/Cable Type Discrete
Durability 25 Cycles
Wire/Cable Gauge 22 AWG
Contact Pattern RECTANGULAR
Insertion Force-Max 8.896 N
Insulation Diameter 1.52 mm
Contact Rating (Current) 5A
Housing Color Red, White
UL Flammability Code 94V-2
Contact Gender Female
Body Breadth 0.305 inch
Number of Contacts 7
Shrouding No
Approval Agency CSA
Reliability COMMERCIAL
Voltage - Rated AC 250V
Current Rating 5A
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Fastening Type Ramp
HTS Code 8536.69.40.40
Number of Rows 1
Color Red
Min Operating Temperature -67°C
Max Operating Temperature 221°C
Connector Type Connector, Receptacle, Socket
ECCN Code EAR99
Termination IDC
Pbfree Code no
JESD-609 Code e0
Packaging Bulk
Dimensions
Height 7.75mm
Length 17.78mm
Width 7.75mm
Plating Thickness 5.08μm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-2
Lead Free Not Applicable
Physical
Housing Material Nylon
Mount Free Hanging
Contact Plating Tin
Contact Material COPPER ALLOY
