644464-5
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
CONN RECEPT 5POS MTA-156 24AWG
PDF
/
Inventory: 1386
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material PHOSPHOR BRONZE
Contact Plating Tin
Mount Cable, Free Hanging
Housing Material Nylon
Underplate Material Nickel
Technical
Packaging Bulk
JESD-609 Code e3
Pbfree Code no
Termination IDC
ECCN Code EAR99
Connector Type Connector, Receptacle, Socket
Max Operating Temperature 221°C
Min Operating Temperature -67°C
Color White
Number of Rows 1
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 3.9624mm
Orientation Right Angle
Depth 9.02mm
Current Rating 7A
Voltage - Rated AC 600V
Reliability COMMERCIAL
Approval Agency CSA
Shrouding No
Number of Contacts 5
Contact Gender Female
UL Flammability Code 94V-2
Contact Style SQ PIN-SKT
Contact Resistance 3mOhm
Body/Shell Style PLUG
ELV Non-Compliant
Max Voltage Rating (AC) 600V
Wire/Cable Type Discrete
Wire/Cable Gauge 24 AWG
Contact Pattern RECTANGULAR
Insulation Diameter 2.41 mm
Contact Rating (Current) 7A
Wire Size (Min) 22 AWG
Wire Size (Max) 22 AWG
Dimensions
Height 9.02mm
Length 19.812mm
Plating Thickness 5.08μm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-2
Lead Free Not Applicable
